2100-956SIPC2 (Surface Mount)

(Click for additional views)
Dimensions:
Face Plate: 10" H x 6-17/25" W
Back Box: 9-7/8" H x 6-1/2" W x 2-3/10” D
Cover: 9-3/4” H x 6-1/2” W x 1-1/4” D
Style: Stainless Steel with Cover

Code Compliance:

• International Building Code (IBC)
• National Fire Protection Association (NFPA)
• Americans Disabilities Act (ADA)

Power Requirements:

• Requires power over Ethernet at 802.3af
• Ethernet power must include a battery backup system in case of power loss

Wiring Requirements:

• Requires Cat5e or better cable (maximum length of 300' between network switches)

Programming Features:

• On-site programming
• Programmable with up to 2 emergency numbers
• Recordable location message (18 seconds)

Phone Capabilities:

• Automatic dialer (31 digit programmable memory)
• Automatic answer feature with audible ring
• Compatible with Command Center for in-building rescue coordination

Optional Features:

• Add model 2500-VOIPM to supervise the complete RATH® IP system

Specifications:

• Mounting: Surface Mount
• Warranty: 2 years

Downloads:

• 2100-956SIPC2 Data Sheet
• Overview - IP Command Center Call Boxes
• IP Call Boxes Installation & Operations
• Engineering Specifications
• Required Mounting Heights
